Overview
The Family Hard Shell is a four-season ABS rooftop tent built for drivers who want a large, weatherproof sleeping space in a compact, low-profile shell. It opens to a generous sleeping footprint while keeping your bedding inside the tent, so you can arrive at camp, release the latches, and be ready for the night in minutes. This model is sized for 3–5 people, making it a solid option for small families or couples who like extra room.
Four-season protection
The outer shell is made from ABS plastic, which forms a rigid, impact-resistant lid that seals the tent on the road and sheds rain and snow at camp. The rainfly uses 420D polyester Oxford, waterproof to 2500 mm and treated for UV and mold resistance, adding another layer of protection over the sleeping area. The tent body is 280 g rip-stop canvas, also waterproof to 2500 mm, so the fabric itself holds up to prolonged wet weather.
With the user rule that all hard shells are four-season, this tent is intended to be used year-round when combined with suitable bedding and attention to local conditions.
Setup and access
At camp, you release the shell latches and lift the top—gas struts assist the opening, so most of the work is done for you. The tent is accessed via an aluminum telescopic ladder, which adjusts to your vehicle height and tucks away when closed. Because your mattress and bedding can stay inside the shell, setup and pack-down stay fast and consistent, even on quick overnight stops.
Interior space and comfort
The Family Hard Shell provides a sleeping footprint of 182 x 210 cm (about 72 in x 83 in, roughly 6 ft x 6 ft 11 in). That’s enough room for 3 adults, or up to 5 people if some are kids or if you pack more tightly.
A high-density 3 cm (about 1.2 in) foam mattress is included, with a waterproof, washable cover. It’s not bulky, which keeps the shell slim, but it does give a consistent, flat surface compared to sleeping on uneven seat backs or cargo. The canvas walls and fly create a dark, sheltered interior with windows that can be opened for airflow while the built-in mesh keeps insects out.
Construction and materials
Inside the fabric, the tent is built around a rigid ABS shell and an aluminum frame. The combination keeps weight reasonable while providing a solid platform that bolts to standard crossbars or rack systems. All main fabrics are rip-stop and treated for water, UV, and mold resistance, so the tent is aimed at repeated use rather than occasional weekends only. The aluminum telescopic ladder resists corrosion, and the included mounting hardware is designed to work with common roof rack setups.
Optional accessories from the manufacturer include a large awning, annex room, LED lighting, anti-condensation mat, shoe bags, and an insulation layer, allowing you to tune the setup for colder climates or longer trips.
Key features
-
Four-season ABS hard shell design – rigid upper and lower shell protect the tent on the road and in bad weather.
-
Sleeping area 182 x 210 cm (approx. 72″ x 83″) – suitable for 3 adults or up to 5 people if some are children.
-
High-density 3 cm foam mattress – integrated sleeping pad with waterproof, washable cover.
-
420D polyester Oxford rainfly – waterproof 2500 mm, UV and mold resistant for long-term exposure.
-
280 g rip-stop canvas body – waterproof 2500 mm with UV and mold resistance, tougher than standard tent fabric.
-
Aluminum telescopic ladder – adjustable height ladder for secure access to the tent.
-
ABS shell – impact-resistant, low-profile housing that stays on the roof full-time.
-
All mounting parts included – brackets and hardware supplied by the manufacturer.
-
Optional accessories – big awning, annex room, LED light, anti-condensation mat, shoe bags, and insulation layer available from the supplier.
Technical specifications – Family Hard Shell
Category
-
Four-season hard shell rooftop tent
Sleeping capacity
-
3–5 person
Sleeping footprint
-
182 x 210 cm
-
Approx. 72 in x 83 in (about 6 ft x 6 ft 11 in)
Closed / packing size
-
200 x 135 x 38 cm
-
Approx. 78.7 in x 53.1 in x 15.0 in
-
Roughly 6 ft 7 in x 4 ft 5 in x 15 in
Weights
-
Gross weight: 80 kg (about 176 lb)
-
Net weight: 67 kg (about 148 lb)
Shell and fabric
-
Shell: ABS
-
Rainfly: 420D polyester Oxford, waterproof 2500 mm, UV and mold resistant
-
Tent body: 280 g canvas rip-stop, waterproof 2500 mm, UV and mold resistant
Mattress
-
High-density foam, 3 cm (1.2 in) thick, waterproof washable cover
Ladder
-
Aluminum telescopic ladder
Included hardware
-
Mounting brackets and install parts
Manufacturer accessory options (for reference)
-
Big awning
-
Annex room
-
LED light
-
Anti-condensation mat
-
Shoe bags (pair)
-
Insulation layer
